Forland C-19

This is the most special commercial truck in Pakistan. Enjoy the 9-feet deck which can carry 1.5 tons payload with ease. It comes with an 1809 cc Diesel Engine, a one-of-its-kind reverse parking sensor, an electronic power steering, and an air conditioning option.

General Information

There is no Single Truck in Pakistan with the same feature-set at a close price (let alone similar). The only competitor for our C19 specs costs almost twice the price of our Pakistani Truck! In this category of commercial trucks, C19 offers the best value for money.

G.V.W

2880 Kg

Drive System

Manual

Minimum Speed

90 KM/H

Displacement

1809 CC

Detailed Specs

  • Overall Length: 4470 mm
  • Overall Width: 1508 mm
  • Overall Height: 1905 mm
  • Cargo Length Inner: 2800 mm
  • Cargo Width: 1508 mm
  • Cargo Height: 320 mm
  • Tread (F/R): 1260/1260 mm
  • Overhang (F/R): 895/1119 mm
  • Turning Radius: 5.5 mm
  • Ground Clearance: 180 mm
  • Frame: 130x50x4 mm
  • Wheelbase: 2456mm
  • Payload: 1500 Kg
  • Kerb Weight: 1250 Kg
  • Front Axle: 1000 Kg
  • Rear Axle: 1500 Kg
  • G.V.W: 2880 Kg
  • Model: LL480QB
  • Type: Vertical, Inline, water cooled, four-stroke, naturally aspirated
  • Valve: 8
  • Bore x Stroke: 80×90 mm
  • Compression Ratio: 18.0:1
  • Fuel Type: Diesel
  • Displacement: 1809 CC
  • Emission Standard: Euro 1
  • Power/RPM: 39/3000 HP/RPM
  • Torque/RPM: 97/2200 NP/RPM
  • Fuel Tank: 40 Litre
  • Gradeability: 25%
  • Maximum Speed: 90 Km/h
  • Model: 5T70
  • Type: Manual
  • Drive System: 5 Speed
  • Gear Ratio: I:4.605 II:2.693 III”1.645 IV:1.000 V:0.839 R:3.947
  • Clutch: Diaphragm-spring Clutch 215
  • Front: Hydraulic Disc Brake
  • Rear: Hydraulic Drum Brake
  • Front: Rigid Axle Suspension
  • Rear: Rigid Axle Suspension
  • Steering: Recirculating Ball type, Electric Power Steering
  • Tyre: 175/70R14LT (Rear Single)
  • Optional: AC

Forland C-19

The payload platform of C-SERIES (Cargo Trucks) is ranging from 1 to 7.5T. It is fitted for modification of bravo box trucks, stake trucks wrecker, refrigerator trucks, aerial platform trucks etc. Forland C-SERIES (Cargo Trucks) have the features of strong load capacity, good trafficability, high efficient, and reliable etc. They are mainly used for the transportation of food, household items, agricultural and sideline products or other LTL goods in the urban area, intercity, or the transportation between cities and suburbs. It provides a variety of solutions for the city transportation.
